V10 iparts now support custom lengths as well as support for materials Note the new Unset button next to the OK button at the base of the dialogue box. The skeleton file is now automatically selected when authoring an iBox. When renaming your files this will not interfere with the iBox functionality.
IBox now aligns with the Autodesk Vault Copy Design process with a unique identifier for it’s base component.
Now in v10 it will orientate the grain direction along the longest length of the bounding box which gives you more accurate BOM specification results. You would then need to adjust the orientation to meet the longest edge requirement. When applying a texture to a curved part in v9 it orientated along the x axis by default. Optimise Part Orientation for grain direction Increasing by 20mm as the example shown below.Įnhanced indicators show panel orientation and grain direction. Located under Woodwork for Inventor Settings > Design tab You can now set an allowance for over sizing slant edges on a panel globally. Multi panel or edge over sizing can be achieved working similar to the grain direction control. More control is achieved with the new layout dialogue. Adjust covers or material fills all in one go. You can now Control grain direction on multiple panels. This release excels by building on it’s foundations to deliver some impressive enhancements. It’s got a new logo but the devil is in the detail. View graham-mansfield-4b39b287’s profile on LinkedIn.View mansfieldgraham’s profile on Twitter.“The software for Woodworkers application, Woodwork for Inventor that accelerates the whole design to manufacturing process by enabling the user to generate simple to complex projects quickly, automating the generation of cutting list tables as well as interfacing to a variety of CNC machines”.
